1. This machine adopts a horizontal cylindrical structure with a reasonable structure.
2. Inflatable sealed drive shaft, can be switched to water during cleaning.
3. Fluidized granulation results in approximately spherical particles with good flowability.
4. Reduce adhesive by 25% compared to traditional processes and shorten drying time.
5. Drying for 2 minutes per batch and granulation for 1-4 minutes can increase efficiency by 4-5 times compared to traditional processes.
6. Completed in the same closed container, drying wet mixing granulation, process reduction, in compliance with GMP standards.
7. The entire operation has strict safety protection measures.
Type | A | B | C×D | E | F |
50 | 320 | 950 | 1250×800 | 970 | 1650 |
150 | 420 | 1000 | 1350×800 | 1050 | 1750 |
200 | 500 | 1100 | 1650×940 | 1450 | 2050 |
250 | 500 | 1160 | 1650×940 | 1400 | 2260 |
300 | 550 | 1200 | 1700×1000 | 1400 | 2310 |
400 | 670 | 1300 | 1860×1100 | 1550 | 2410 |
600 | 750 | 1500 | 2000×1230 | 1750 | 1610 |
Name | Modle | ||||||
50 | 150 | 200 | 250 | 300 | 400 | 600 | |
Volume (L) | 50 | 150 | 200 | 250 | 300 | 400 | 600 |
Yield (kg) | 15 | 50 | 80 | 100 | 130 | 200 | 280 |
Mixing speed (r.p.m.) | 200/400 | 180/270 | 180/270 | 180/270 | 140/220 | 106/155 | 80/120 |
Hybrid power (kw) | 4/5.5 | 6.5/8 | 9/11 | 9/11 | 13/16 | 18.5/22 | 22/30 |
Cutting speed (r.p.m.) | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 |
Cutting power (kw) | 1.3/1.8 | 2.4/3 | 4.5/5.5 | 4.5/5.5 | 4.5/5.5 | 6.5/8 | 9/11 |
Compressed air consumption (m3/min) | 0.6 | 0.9 | 0.9 | 0.9 | 1.1 | 1.5 | 1.8 |
